Bopla Cabinets and Enclosures
- from idea to production!


Bopla adapts cabinets and enclosures according to your individual specifications!

For many years, the production of specially designed enclosures and components using various materials and processing methods has been part of Boplas range of services and products. In addition, and on request, Bopla produce prototypes for error analysis and very small series for field tests. The choice of production process depends largely on the type and use of your cabinet and on the batch size. Bopla can produce prototypes quickly and at low cost, but making a special injection or casting tool is only worth for large quantities.

Bopla_Bilde_Generell

Bopla - a proper production process

When you choose the right production process, the type and use of the cabinets, as well as the series play important roles. The plastic injection molding system provides great design freedom. The use of different surfaces can create eye-catching designs such as a polished logo. Die-cast cabinets are ideal for use in harsh environments - the robustness of the material ensures that they stand out, and the material itself also creates a special first-class impression for the user.

Profile enclosures are used when good heat dissipation and length variation are required. Individual cabinet sizes can be made simply by cutting the profiles to the desired length. There is also a solution when smaller quantities are needed. Individual cabinets can be produced using punching and bending technology - quickly, efficiently and often without investment costs. A wide range of materials is available, from aluminum to stainless steel. In addition, almost all surface designs are possible.

Bocube Alu S – screws, not hinges

The new Bocube Alu S models without hinges are particularly recommended for tight installation situations that do not offer enough space for the lid to swing open areas of application in which the enclosure is exposed to extremely high vibration loads

Bocube Alu S convinces with the following features:

Four cover screws replace the hinge, making the new enclosure series predestined for particularly mechanically demanding applications. Of course, Bocube Alu S also complies with the usual protection classes of IP66 / 68 (1.2m; 2h) / 69 found in the standard series. An optional silicone cover seal is suitable for use even under extreme temperature conditions. In addition to the variants in the standard light grey and graphite grey colours, special colours can also be provided on request



Bopla Alu S from Etm4u

The closure options of Bocube Alu at a glance:

thumbnail_image006

Bocube Alu S in use:

thumbnail_image003

Also from BOPLA: Bocube & Bocube Alu - the new generation of industrial enclosures

Custom-designed enclosures – examples of applications

Here is a small selection of customers’ projects which have already been implemented. Whether plastic injection-moulding, aluminium die-casting or bent sheet metal technology are best – working together with you, we determine the optimal manufacturing process for your application.

csm_Individuelle_Gehaeuse_29_dceb456e19
csm_Individuelle_Gehaeuse_08_7ab6bca58d
csm_Individuelle_Gehaeuse_21_778e8df64b

Plastic injection-moulded enclosure for mounting on a DIN rail

Bent sheet metal enclosure with especially attractive lacquering

Bent sheet metal enclosure for 19" racks in the audio sector

csm_Individuelle_Gehaeuse_13_33e7b636fa
csm_Individuelle_Gehaeuse_16_911884ea83
csm_Individuelle_Gehaeuse_28_8b05e60cda

Custom-designed aluminium die-cast enclosure

Two-part bent sheet metal enclosure for medical technology

Two-colour modular plastic injection-moulded enclosure for fixing on a top hat rail

If you would like more information or have any questions on any of our products or services, please do not hesitate to contact us here. We would be happy to assist you in any way we can.
