266 Card-Lok
€0.00
art.nr
MV266-2.80EHLK
266 Card-Lok- price on request
nVent Schroff, The Series 266 features a ridged shafted design which provides more uniform clamping force over the length of the Card Lok, while maintaining wedge and body alignment for easier installation.
Screw actuated
Weight 0.89 g/cm
Flexible mounting options
3 segment, shafted design
Profile 5.72 mm x 5.84 mm
Length 96.5 mm to 325 mm, 12.7 mm increments
Min expansion 7.37 mm
Average clamp force (4.80", black anodized) = 238 lbs
For cold wall applications
| art.nr | MV266-2.80EHLK |
|---|---|
| Country of origin | Germany |
| Manufacturer | Schroff |
| Normal Delivery time | Call us |
| Customs no. | 4036088052088 |
| UNSPSC | 30211502 |
| Datasheet | click here |
| Product homepage | configure here |
| Produsentens hjemmeside | click here |
| Manufacturer's part.nr | MV266-2.80EHLK |
