CONFIGURATORS FOR NVENT SCHROFF

Introducing a new generation of configurators with an intuitive graphical user interface, dynamic CAD generation and full integration into website without additional software installation.

  • No registration needed, but extra features for registered users.
  • Functional graphical interface with drag and drop in an instant 3D visualization.
  • Components libraries for easy selection of the parts, plausibility check ensures valid results.
  • Modification module to add cutouts, with cutout library, and printing options.
  • More than 30 CAD file formats available for exportation, direct opening into CAD software, smart 3D PDF technical specification. After saving configuration, bill of material is submitted into website project list with direct pricing and request for quote. As a nVent Schroff distributor and reseller, Etm4u will of course help you find your way.

EUROPACPRO SUBRACK CONFIGURATOR

Intelligent, online EuropacPRO subrack configurator

  • 3D Drag and drop design
  • Error checking logic
  • Instant CAD and BOM documentation

FRONT PANEL CONFIGURATOR

An extensive range of front panels to provide a finishing touch to the front of your chassis – visually  and functionally.

The front panel configurator enables you to quickly design your solution with cutouts and paint/print in addition to the complete CAD and BOM documentation.


NOVASTAR CABINET CONFIGURATOR

  • Type of protection up to IP 40
  • Bolted, die-cast frame with Al extrusions
  • Cabinet width only 553 mm
  • Static load-carrying capacity up to 400 kg
  • Colours: RAL 7021 or colour combination RAL 7021/ RAL 7035

VARISTAR CP CABINET CONFIGURATOR

  • Infinitely variable, extremely efficient and amazingly universa
  • Broad range of standard articles available to configure the cabinet
  • UL 2416 compliance in addition to all other compliances
  • Streamlined design

RACK SAFETY PLUS PRODUCT CONFIGURATORS

The fastest way to define your PDU including emergency safety functions. Rack Safety Plus, the 19“ 3 U Power Distribution Unit with Emergency Stop System, which can be modified based on your application needs. Select the power input, power output, additional features such as a surge arrester or EMC filter based on your hardware infrastructure.


RATIOPACPRO STYLE: DESKTOP ENCLOSURE CONFIGURATOR

Design your Difference: Customize Your Desktop Cases with Ease. Start configuring your RatiopacPRO Style desktop case now and create a tailored solution that perfectly meets your needs!
